GE IC220SDL840

GE Fanuc IC220SDL840 | VersaMax Network Interface Unit | RS-485 Master | 115.2 Kbps | Serial Expansion Master | DIN Rail

Overview

The GE Fanuc IC220SDL840 is a VersaMax serial expansion master module that controls communication with multiple slave modules over an RS-485 network. Designed for use with VersaMax Micro and Nano PLCs, this unit supports data rates up to 115.2 Kbps, enabling fast and reliable distributed I/O management.

The module mounts directly on a DIN rail, offering flexibility and scalability in compact control systems.

• Interface Type: RS-485 Serial (2-wire)

• Role: Master device for serial expansion

• Max Baud Rate: 115.2 Kbps

• Connection Support: Multiple VersaMax slave I/O modules

• Mounting Style: DIN rail

• Status LEDs: Communication and power indication

• Configuration: Rotary switches for address and baud rate

Technical Specifications

• Model Number: IC220SDL840

• Network Type: RS-485 Serial

• Data Rate: Up to 115.2 Kbps

• Max Number of Slaves: 7

• Power Source: Supplied through I/O base

• Isolation: Yes (network and logic isolation)

• Mounting Method: DIN rail

• Operating Temperature: -20°C to 60°C

• Certifications: UL, CE

Applications

• Master-slave control systems with VersaMax I/O

• Serial network-based distributed I/O architectures

• Factory automation and OEM machinery

• Remote I/O expansion using RS-485

Why Choose the IC220SDL840?

• Master Control: Manages multiple I/O slaves on one RS-485 bus

• Fast & Reliable: Supports 115.2 Kbps data transfer

• Compact Design: Saves space with DIN rail mounting

• Easy Integration: Simple rotary switch setup and LED diagnostics

Order Now

The GE Fanuc IC220SDL840 serial expansion master module is in stock and available for immediate global shipment.

NEW product in original sealed packaging. The product may be of older version or design. The packaging may have markings, signs of discoloration, and wear. DDPARTSSOLUTION Warranty: 1 Year. Manufacturer's Warranty and Support NEVER apply
