GE IC220MDD843

GE Fanuc IC220MDD843 | VersaMax Micro I/O Module | 24VDC | 8 Inputs / 6 Outputs | Source/Sink | Relay Outputs | DIN Rail

Overview

The GE Fanuc IC220MDD843 is a VersaMax Micro I/O module that features 8 DC inputs and 6 relay outputs. Designed for 24VDC control systems, this unit supports both sourcing and sinking inputs and provides relay-based output switching for broader load compatibility.

This compact, DIN rail-mountable module is ideal for distributed control applications within industrial automation systems.

• Inputs: 8 digital inputs (24VDC, sink/source selectable)

• Outputs: 6 relay outputs (form A)

• Output Type: Dry contact, SPST

• Input Voltage: 24VDC nominal

• Mounting: DIN rail

• Indicators: LEDs for I/O channel status

• Isolation: Input/output and logic isolation

Technical Specifications

• Model Number: IC220MDD843

• Input Type: 24VDC, sink/source configurable

• Input Points: 8

• Output Type: Relay (form A, SPST)

• Output Points: 6

• Output Voltage Range: Up to 250VAC / 30VDC

• Max Output Current: 2A per point

• Power Supply: 24VDC

• Mounting Style: DIN rail

• Operating Temperature: -20°C to 60°C

• Certifications: UL, CE

Applications

• Machine control panels

• Distributed I/O systems using VersaMax Micro PLCs

• Industrial automation and discrete control

• OEM equipment integration

Why Choose the IC220MDD843?

• Dual-Function I/O: Combines inputs and relay outputs in a compact module

• Flexible Logic Support: Sink or source input compatibility

• DIN Rail Ready: Easy integration into control cabinets

• High Reliability: Ideal for switching a wide variety of loads

Order Now

The GE Fanuc IC220MDD843 VersaMax I/O module is available for immediate order with fast worldwide delivery.

NEW product in original sealed packaging. The product may be of older version or design. The packaging may have markings, signs of discoloration, and wear. DDPARTSSOLUTION Warranty: 1 Year. Manufacturer's Warranty and Support NEVER apply
