Fluke 59 MAX

Fluke 59 MAX – Overview

The Fluke 59 MAX is a compact, rugged infrared thermometer designed for quick and safe non-contact surface temperature measurements. With an 8:1 distance-to-spot ratio, a laser pointer for targeting, and a temperature range from –30 °C to +350 °C, it is ideal for electrical, HVAC, and mechanical applications. Built to withstand a 1-meter drop and rated IP40, it ensures durability in demanding environments.

Key Features

• Temperature range: –30 °C to +350 °C (–22 °F to +662 °F)

• 8:1 distance-to-spot ratio for accurate targeting

• Single laser pointer for precise aim

• MIN, MAX, AVG, and DIF measurement modes

• Hi/Lo alarms for quick detection of abnormal readings

• Adjustable emissivity (0.10 to 1.00)

• Backlit display for clear visibility

• Drop tested to 1 meter

• Compact, one-hand design

• IP40 protection rating

Technical Specifications

• Model: Fluke 59 MAX

• Temperature Range: –30 °C to +350 °C

• Accuracy:
    • ≥ 0 °C: ±2.0 °C or ±2.0% of reading
    • –10 °C to <0 °C: ±2.0 °C
    • < –10 °C: ±3.0 °C

• Resolution: 0.1 °C / 0.2 °F

• Response Time: < 500 ms

• Repeatability: ±1% of reading or ±1.0 °C

• Spectral Response: 8 µm to 14 µm

• Distance-to-Spot Ratio: 8:1

• Emissivity Range: 0.10 to 1.00 (adjustable)

• Display: Backlit LCD

• Power Supply: 1 × AA alkaline battery

• Battery Life: ~12 hours (with laser and backlight on)

• Dimensions: 156 × 80 × 50 mm

• Weight: ~220 g

• Operating Temperature: 0 °C to +50 °C

• Storage Temperature: –20 °C to +60 °C (without battery)

• Humidity: 10% to 90% RH, non-condensing at 30 °C

• Operating Altitude: up to 2000 m

• Storage Altitude: up to 12,000 m

• Safety & Compliance: EN/IEC 61010-1, Class II laser

• Protection Rating: IP40

Applications

• Electrical panel and wiring hot spot detection

• HVAC and refrigeration diagnostics

• Motor, pump, and bearing temperature monitoring

• Building inspections and energy audits

• Quick surface checks in industrial maintenance

Why Choose Fluke 59 MAX

• Wide temperature range with fast response time

• Lightweight and portable design for field use

• Reliable durability with drop and IP40 protection

• Enhanced measurement modes for professional diagnostics

Order Now

The Fluke 59 MAX Infrared Thermometer is available and ships worldwide.

NEW product in original sealed packaging. The product may be of older version or design. The packaging may have markings, signs of discoloration, and wear. DDPARTSSOLUTION Warranty: 1 Year. Manufacturer's Warranty and Support NEVER apply
