Fluke 179

Fluke 179 – Industrial True-RMS Digital Multimeter

Overview

The Fluke 179 is a rugged, full-featured digital multimeter designed for HVAC, electrical, industrial, and electronics work. It includes true-RMS measurements, a built-in thermometer, analog bar graph, backlight for low-light conditions, and both manual and auto ranging. With high safety ratings and robust protection, it’s made for demanding field use.

Key Features

• True-RMS for accurate AC/DC readings

• Measures up to 1000 V (AC/DC) and 10 A (AC/DC)

• Temp measurement from -40 °C to +400 °C with included thermocouple

• Resistance up to 50 MΩ; capacitance up to 10 000 µF

• Frequency up to 100 kHz; analog bar graph

• Min/Max/Average recording, Display Hold and Auto Hold

• Backlit display; robust over-molded construction

Technical Specifications

• Model: Fluke 179

• Voltage DC: up to 1000 V; accuracy ±(0.09 % + 2)

• Voltage AC (True-RMS): up to 1000 V; accuracy ±(1.0 % + 3)

• Current DC: up to 10 A; accuracy ±(1.0 % + 3)

• Current AC: up to 10 A; accuracy ±(1.5 % + 3)

• Resistance: up to 50 MΩ; accuracy ±(0.9 % + 1)

• Capacitance: up to 10 000 µF; accuracy ±(1.2 % + 2)

• Frequency: up to 100 kHz; accuracy ±(0.1 % + 1)

• Temperature (with probe): -40 °C … +400 °C; accuracy ±(1.0 % + 10)

• Operating Temperature: -10 °C … +50 °C

• Storage Temperature: -30 °C … +60 °C

• Display Counts: 6,000 counts; updates ~4 times/sec; bar-graph 33 segments (~40 updates/sec)

• Safety Category: CAT III 1000 V; CAT IV 600 V

• Battery Life: ~200 hours typical (alkaline, without backlight)

• Size: approx. 43 × 90 × 185 mm

• Weight: ~420 g

Applications

• Electrical maintenance and troubleshooting in industrial settings

• HVAC systems, motor and pump diagnostics

• Field work where a durable meter with a wide range and safety protections is required

• Tasks requiring temperature measurement, capacitance, and true-RMS signal integrity

Why Choose the Fluke 179

• Excellent accuracy in AC and DC across high voltages and currents

• Wide temperature range for harsh environments

• Advanced features like Min/Max/Average and built-in thermometer reduce need for extra tools

• Strong safety ratings and rugged design

Order Now

The Fluke 179 is part of Fluke’s 170-Series industrial multimeters. Available for purchase. Ships worldwide.

NEW product in original sealed packaging. The product may be of older version or design. The packaging may have markings, signs of discoloration, and wear. DDPARTSSOLUTION Warranty: 1 Year. Manufacturer's Warranty and Support NEVER apply
