Omron NXSL3300 | 2-Axis Servo Drive Controller

Omron NXSL3300 | 2-Axis Motion Controller for High-Speed EtherCAT Servo Control

Overview

The Omron NXSL3300 is a 2-axis servo drive controller designed for use within the NX-series modular PLC platform. It provides high-performance synchronized motion control over EtherCAT, making it ideal for high-speed automation systems that demand precision, scalability, and seamless integration with Omron’s Sysmac environment.

Key Features

• Axes Supported: 2-axis servo control

• Communication: EtherCAT (CoE compliant)

• Integrated with Sysmac Studio: Unified environment for programming, simulation, and monitoring

• High-Speed Synchronization: Precision motion control with sub-millisecond response

• Multi-Axis Coordination: Supports interpolation, gearing, cam profiles

• Compact Module Design: Saves space in control panels

• LED Indicators: Status and diagnostics at a glance

• Plug-in Module: Connects directly to NX PLC rack

• Conformance Tested: EtherCAT certified

Technical Specifications

• Model: NXSL3300

• Axes Controlled: 2

• Protocol: EtherCAT (based on CiA402)

• Cycle Time: As low as 500 µs

• Power Supply: Supplied from NX rack

• Integration: NX-series CPU (NJ/NX1/NX7)

• Mounting: DIN rail via NX I/O system

• Operating Temp: 0°C to +55°C

• Protection Rating: IP20 (module only)

• Dimensions: Approx. 12 × 100 × 70 mm

• Weight: Approx. 100 g

Applications

• Robotic Pick & Place Systems

• Packaging Machinery

• Material Handling

• Cut-to-Length and Flying Shear Applications

• Multi-Axis Motion Synchronization

Why Choose Omron NXSL3300?

• Built for EtherCAT motion networks within Sysmac automation

• Enables advanced motion profiles like camming and electronic gearing

• Flexible 2-axis controller for compact and scalable machines

• Simplifies programming through Sysmac Studio's all-in-one platform

NEW product in original sealed packaging. The product may be of older version or design. The packaging may have markings, signs of discoloration, and wear. DDPARTSSOLUTION Warranty: 1 Year. Manufacturer's Warranty and Support NEVER apply
