Beckhoff EL5021

Beckhoff EL5021

Overview

The Beckhoff EL5021 is a 1-channel stepper motor controller terminal for the EtherCAT I/O system. It delivers up to 50 V DC and 5 A output current, providing precise control of stepper motors in compact automation environments. With integrated diagnostics and direct TwinCAT support, it enables reliable and efficient motion control.

Key Features

• Controls a single stepper motor channel

• Output voltage: up to 50 V DC

• Output current: up to 5 A

• Supports microstepping for precise positioning

• Diagnostic LEDs for easy monitoring

• Compact EtherCAT terminal design (12 mm width)

• Fully compatible with TwinCAT Motion Control

Technical Specifications

• Part Number: EL5021

• Manufacturer: Beckhoff

• Function: Stepper motor controller terminal

• Channels: 1 motor axis

• Supply Voltage: 50 V DC max.

• Output Current: 5 A max.

• Width: 12 mm

• Interfaces: EtherCAT

• Mounting: DIN rail (EtherCAT Terminal system)

• Operating Temperature: –25 °C to +60 °C

Applications

• Stepper motor control in machine automation

• Positioning tasks in packaging and labeling

• Robotics and material handling systems

• Laboratory and test automation equipment

• Modular motion control in EtherCAT networks

Why Choose the EL5021

• Compact and cost-effective motion control solution

• 1-channel stepper motor controller in 12 mm width

• High current and voltage support for industrial motors

• Diagnostic LEDs simplify troubleshooting

• Direct integration with TwinCAT Motion Control

Order Now

The Beckhoff EL5021 EtherCAT stepper motor controller terminal is available and ships worldwide.
