Beckhoff EL2798

Beckhoff EL2798

Overview

The Beckhoff EL2798 is an 8-channel digital output terminal for switching 24 V DC signals with a maximum load of 0.5 A per channel. It integrates seamlessly with Beckhoff’s modular I/O system via the K-bus, offering compact design and reliable performance for industrial automation environments.

Key Features

• 8 digital output channels

• Output voltage: 24 V DC

• Max. load: 0.5 A per channel

• Compact and modular design for K-bus integration

• Short-circuit and overload protection

• Industrial-grade reliability

Technical Specifications

• Beckhoff Code: EL2798

• Type: Digital Output Terminal

• Channels: 8

• Output Voltage: 24 V DC

• Max. Current per Channel: 0.5 A

• Bus Connection: K-bus

• Operating Temperature: 0 °C to +55 °C

• Mounting: DIN rail

• Dimensions: Standard Beckhoff terminal size

• Certifications: CE, UL

Applications

• Industrial machine control

• Signal switching in automation systems

• Process automation

• Modular I/O expansions

• Test and measurement setups

Why Choose Beckhoff EL2798?

• Compact 8-channel output terminal

• Reliable switching of 24 V DC signals

• Seamless integration with Beckhoff I/O system

• Designed for robust and flexible industrial use

Order Now

Enhance your automation systems with the Beckhoff EL2798 — a reliable and compact 8-channel digital output terminal for precise control.
