Beckhoff CU2508

Beckhoff CU2508

Overview

The Beckhoff CU2508 is an 8-port EtherCAT multiport switch card for PCI Express systems. It allows the parallel operation of multiple EtherCAT segments, reducing system cycle times and increasing real-time performance in demanding automation tasks. Designed for high-speed data throughput, the CU2508 is the ideal solution for PC-based control platforms requiring advanced EtherCAT networking.

Key Features

• 8-port EtherCAT multiport switch card

• PCI Express interface for industrial PCs

• Enables parallel EtherCAT segment processing

• Reduces cycle times in complex networks

• Real-time communication with EtherCAT masters

• Diagnostic LEDs for link and activity monitoring

• Designed for industrial PC-based control systems

Technical Specifications

• Part Number: CU2508

• Manufacturer: Beckhoff

• Type: Multiport EtherCAT switch card

• Ports: 8 × RJ45 EtherCAT

• Interface: PCI Express

• Data Rate: 100 Mbit/s (full duplex)

• Dimensions: Standard PCIe card format

• Operating Temperature: 0 °C to +55 °C

Applications

• High-performance PC-based automation systems

• Parallel EtherCAT networking for motion control

• Robotics and CNC systems with short cycle times

• Process automation with distributed EtherCAT segments

• Industrial PCs requiring advanced EtherCAT expansion

Why Choose the CU2508

• Expands PC-based controllers with 8 EtherCAT ports

• Increases performance by enabling parallel EtherCAT tasks

• Real-time networking for demanding automation

• Compact PCIe card form factor for easy integration

• Backed by Beckhoff’s EtherCAT expertise

Order Now

The Beckhoff CU2508 8-port EtherCAT multiport switch PCIe card is available and ships worldwide.

NEW product in original sealed packaging. The product may be of older version or design. The packaging may have markings, signs of discoloration, and wear. DDPARTSSOLUTION Warranty: 1 Year. Manufacturer's Warranty and Support NEVER apply
