Banner Q12AP6FF50Q3

Banner Q12AP6FF50Q3

Overview

The Banner Q12AP6FF50Q3 is a Q12 Series compact photoelectric sensor designed for precise short-range detection in tight spaces. With diffuse mode sensing, PNP output and fast response, it is ideal for conveyors, robotics, packaging machinery and general automation requiring a small, rugged and reliable sensor.

Key Features

• Diffuse sensing mode — detects objects directly without reflectors

• Compact Q12 housing for tight-space installation

• PNP output for direct PLC integration

• Visible red LED for quick alignment

• Fast response time for high-speed applications

• IP67 sealing for dust and water resistance

• Status and output indicators for easy diagnostics

Technical Specifications

• Model: Q12AP6FF50Q3

• Series: Q12

• Type: Diffuse Photoelectric Sensor

• Sensing Range: Up to 50 mm (depending on target reflectivity)

• Output Type: PNP, Normally Open (NO)

• Light Source: Red visible LED

• Supply Voltage: 10–30 V DC

• Connection: 3-pin M8 quick-disconnect (Q3)

• Housing Material: Durable industrial polymer

• Protection Rating: IP67

• Operating Temperature: –25 °C to +70 °C

• Response Time: Fast switching for moving objects

Applications

• Short-range object detection on conveyors

• Pick-and-place, sorting, and packaging systems

• Robotics end-of-arm tooling with limited space

• Part presence verification in assembly lines

• Harsh environments with dust or splashing water

Why Choose Banner Q12AP6FF50Q3?

• Excellent performance in a compact and economical design

• Quick installation with M8 quick-disconnect

• Durable construction ensures long-term industrial reliability

• Easy alignment and diagnostics using built-in indicators

• Proven Banner Engineering sensing technology

Order Now

Enhance automation in limited spaces with the Banner Q12AP6FF50Q3 — a compact, precise and rugged diffuse photoelectric sensor built for industrial performance.

NEW product in original sealed packaging. The product may be of older version or design. The packaging may have markings, signs of discoloration, and wear. DDPARTSSOLUTION Warranty: 1 Year. Manufacturer's Warranty and Support NEVER apply
