B&R X20SO4120 | 4-Channel Stepper Output Module

B&R X20SO4120 | 4-Channel Stepper Output Module

Overview:

The B&R X20SO4120 is a 4-channel stepper output module, designed for precise control of stepper motors in industrial automation systems. This module ensures high-speed, accurate positioning and integrates seamlessly with B&R X20 controllers, making it ideal for motion control applications.

Key Features:

• 4 Stepper Motor Output Channels – Enables multi-axis motion control.
• High-Speed Pulse Output – Ensures accurate and smooth stepper motor operation.
• Configurable Pulse Frequency – Optimized for precise positioning and speed control.
• Seamless Integration – Designed for B&R X20 automation systems.
• Compact & Modular Design – Space-saving for control panels and motion systems.
• Reliable & High-Precision – Provides consistent and stable performance in motion control applications.

Technical Specifications:

• Model: X20SO4120
• Number of Channels: 4
• Output Type: Pulse Train for Stepper Motors
• Max Output Frequency: Configurable for precise motor control
• Power Supply: Provided via X20 series backplane
• Mounting Type: DIN rail (X20 system rack)

Ambient Conditions:

• Operating Temperature: 0 to 55°C
• Storage Temperature: -25 to 70°C
• Humidity: 10% to 95% (non-condensing)
• Vibration Resistance: 5-9 Hz, 3.5 mm amplitude

Applications:

• Industrial Automation – Provides real-time stepper motor control.
• CNC Machines & Robotics – Enables high-precision motion control.
• Material Handling Systems – Supports smooth and controlled movement.
• Packaging & Assembly Lines – Optimized for automated positioning applications.

Why Choose the B&R X20SO4120?

The B&R X20SO4120 offers high-speed, precise stepper motor control, making it an excellent choice for motion automation applications. With seamless X20 system integration, accurate pulse control, and modular flexibility, it ensures efficient and reliable motion performance in demanding environments.
