Autonics MT4W-DV-4N

Autonics MT4W-DV-4N

Overview

The Autonics MT4W-DV-4N is a high-performance digital panel meter designed for precise DC voltage measurement and monitoring in industrial applications. With its bright 4-digit LED display and compact 1/32 DIN housing, the MT4W-DV-4N ensures easy readability and flexible installation in control panels. This model supports multi-range DC voltage input and provides stable, accurate readings ideal for process control and automation systems.

Key Features

• Measures DC voltage across multiple ranges

• High-visibility 4-digit LED display

• Compact 1/32 DIN (48 × 24 mm) design

• NPN open collector output for process control

• Wide power supply range (100–240 V AC)

• Excellent accuracy and linearity

• Front key operation for simple parameter setup

• CE and UL certified for safety and reliability

Technical Specifications

• Manufacturer: Autonics

• Model: MT4W-DV-4N

• Type: Digital Panel Meter

• Input Signal: DC Voltage (±200 mV / ±2 V / ±20 V / ±200 V selectable)

• Display: 4-digit 7-segment red LED, 8.3 mm height

• Display Range: –1999 to 9999

• Accuracy: ±0.2% of F.S. ±1 digit

• Output Type: NPN Open Collector

• Power Supply: 100–240 V AC, 50/60 Hz

• Sampling Time: 100 ms

• Operating Temperature: 0 °C to +50 °C

• Mounting Type: Panel Mount (1/32 DIN)

• Housing Material: ABS plastic

• Certifications: CE, UL, RoHS compliant

Applications

• DC voltage monitoring in control panels

• Power supply and process equipment supervision

• Laboratory testing and instrumentation

• Industrial automation and process control systems

• Electrical panel voltage indication

Why Choose Autonics MT4W-DV-4N?

• High precision and fast response for DC voltage monitoring

• Easy-to-read LED display with compact form factor

• Reliable performance in demanding industrial environments

• Trusted Autonics build quality and compliance with global standards

Order Now

Enhance your control and monitoring systems with the Autonics MT4W-DV-4N, delivering precise DC voltage display and dependable performance in a compact digital panel meter.

New:

New product in original sealed packaging. The product may be of an older version or design. Packaging may show markings, discoloration, or signs of wear due to storage.

Refurbished:

Refurbished product fully tested, cleaned, and verified for proper operation. Not in original packaging. The item may show minor cosmetic signs resulting from previous handling or use.

Warranty:

DDPARTSSOLUTION Warranty: 1 Year.

Manufacturer’s warranty and support DO NOT apply.
