Autonics AT11DN

Autonics AT11DN

Overview

The Autonics AT11DN is a high-performance capacitive proximity sensor designed for reliable detection of a wide range of materials — including metal, plastic, glass, liquid, and granular substances. With an 11 mm sensing distance and compact rectangular housing, this sensor offers stable operation and easy installation in diverse industrial environments. Its adjustable sensitivity and solid-state output ensure flexible integration into automation and control systems.

Key Features

• Detects metallic and non-metallic objects

• 11 mm sensing distance with stable performance

• Adjustable sensitivity for various materials

• NPN open collector output (normally open)

• Wide voltage range: 12–24 V DC

• LED indicator for easy operation status check

• Compact and durable rectangular housing

• IP66-rated protection against dust and moisture

Technical Specifications

• Manufacturer: Autonics

• Model: AT11DN

• Type: Capacitive Proximity Sensor

• Sensing Distance: 11 mm

• Output Type: NPN, Normally Open (3-wire DC)

• Operating Voltage: 12–24 V DC

• Current Consumption: ≤10 mA

• Response Frequency: 20 Hz

• Sensitivity Adjustment: Built-in potentiometer

• Housing Material: ABS Plastic

• Protection Rating: IP66

• Operating Temperature: –25 °C to +70 °C

• Connection Type: Cable (2 m)

• Certifications: CE, RoHS compliant

Applications

• Level sensing for liquids and powders

• Material detection in packaging and filling lines

• Position sensing in automation systems

• Conveyor and assembly line monitoring

• Non-contact detection in industrial environments

Why Choose Autonics AT11DN?

• Reliable and precise capacitive sensing technology

• Detects a wide range of materials with adjustable sensitivity

• Compact and easy to install in tight spaces

• Backed by Autonics’ reputation for quality and performance

Order Now

Optimize your automation processes with the Autonics AT11DN, delivering dependable, adjustable capacitive sensing for diverse industrial and production applications.

New:

New product in original sealed packaging. The product may be of an older version or design. Packaging may show markings, discoloration, or signs of wear due to storage.

Refurbished:

Refurbished product fully tested, cleaned, and verified for proper operation. Not in original packaging. The item may show minor cosmetic signs resulting from previous handling or use.

Warranty:

DDPARTSSOLUTION Warranty: 1 Year.

Manufacturer’s warranty and support DO NOT apply.
