Allen‑Bradley 1326AB‑B515E‑21‑K5

Allen‑Bradley 1326AB‑B515E‑21‑K5

Overview

The Allen‑Bradley 1326AB‑B515E‑21‑K5 is a high-performance Torque Plus Series AC servo motor featuring an integrated holding brake. Operating at 460 V, it delivers 10.4 Nm of continuous torque at 3000 RPM. Equipped with resolver feedback and housed in a rugged IP65-rated aluminum enclosure, this motor is designed for precision motion control applications where secure stopping and torque are critical.

Key Features

• Three-phase 460 V AC input

• Continuous torque: 10.4 Nm

• Peak torque: approximately 31.2 Nm

• Rated speed: 3000 RPM

• Integrated holding brake (nominal torque ~12–15 Nm)

• Resolver feedback for closed-loop position sensing

• IP65-rated, aluminum housing

• IEC metric flange with keyway

• UL-recognized insulation

• Compatible with Allen‑Bradley 1394, Kinetix, Ultra3000 drives

Technical Specifications

• Model: 1326AB‑B515E‑21‑K5

• Voltage Rating: 460 V AC, 3-phase

• Continuous Torque: 10.4 Nm

• Peak Torque: Approximately 31.2 Nm

• Rated Speed: 3000 RPM

• Brake: Built-in holding brake (~12–15 Nm)

• Feedback Type: Resolver

• Frame Size: 149 mm diameter

• Enclosure Protection: IP65

• Mounting Type: IEC metric flange with keyway

• Housing Material: Aluminum

• Insulation Class: UL-recognized

• Motor Weight: Approximately 23 kg (including brake)

Applications

• CNC machine axes

• Packaging, labeling, and material handling

• Robotics requiring safe stop capability

• Industrial automation with torque and holding control

• Retrofit and upgrade of Allen‑Bradley legacy systems

Why Choose the 1326AB‑B515E‑21‑K5

• Includes built-in brake for secure, power-down holding

• High torque performance for precision applications

• Reliable resolver feedback in demanding environments

• Robust IP65 design for industrial duty

• Direct drop-in fit with Allen‑Bradley drive platforms

Order Now

The Allen‑Bradley 1326AB‑B515E‑21‑K5 servo motor with holding brake is available and ships worldwide—ideal for applications needing precision torque and secure holding.

Looking for more options?

Explore our complete selection of Allen-Bradley 1326AB Servo Motors for high-performance, precise motion control solutions.

You can also browse our full range of Allen-Bradley Servo Motors to find the perfect match for your automation needs.

NEW product in original sealed packaging. The product may be of older version or design. The packaging may have markings, signs of discoloration, and wear. DDPARTSSOLUTION Warranty: 1 Year. Manufacturer's Warranty and Support NEVER apply
