Allen-Bradley 1769-L24ER-QBFC1BK

Allen-Bradley 1769-L24ER-QBFC1BK

Overview

The Allen-Bradley 1769-L24ER-QBFC1BK is a CompactLogix 5370 L2 series controller with integrated I/O, Ethernet/IP communication, and conformal coating. Designed for mid-size applications that demand compactness and performance, it provides flexibility in harsh environments.

Key Features

• 750KB user memory

• Integrated I/O: 16 Digital Inputs, 16 Digital Outputs

• 4 Universal Analog Inputs (AI)

• 2 Analog Outputs (AO)

• Dual Ethernet/IP ports with embedded switch and Device Level Ring (DLR) support

• Conformal coated for harsh environment protection

• USB port for programming and firmware updates

• Compatible with Studio 5000 environment

• DIN rail mountable

Technical Specifications

• Manufacturer: Allen-Bradley / Rockwell Automation

• Part Number: 1769-L24ER-QBFC1BK

• Controller Family: CompactLogix 5370 L2

• User Memory: 750KB

• Integrated Digital Inputs: 16 (24VDC)

• Integrated Digital Outputs: 16 (24VDC sourcing)

• Analog Inputs: 4 Universal (V/mA/RTD/Thermocouple)

• Analog Outputs: 2 (Voltage/Current)

• Ethernet/IP Ports: 2 (embedded switch with DLR support)

• USB Port: 1 (Type B)

• I/O Expansion: Up to 8 additional 1769 I/O modules

• Conformal Coating: Yes (K suffix)

• Mounting: DIN rail

• Power Supply Requirements: 24V DC

• Operating Temperature: 0 to 60 °C

• Certifications: UL, CE, c-UL, RoHS

Applications

• Medium-size machine control systems

• Industrial automation in environments requiring conformal coating

• Multi-protocol Ethernet networks (DLR, star topology)

• Systems needing both analog and digital I/O on board

Why Choose the 1769-L24ER-QBFC1BK

• Reduces cabinet space with integrated I/O

• Enhances reliability in corrosive or humid environments

• Flexible communication with dual Ethernet/IP ports

• Ideal for control systems requiring both analog and digital signals

Order Now

Ensure powerful and space-efficient automation with the CompactLogix 1769-L24ER-QBFC1BK controller.

Return to our CompactLogix Controllers main category to explore all models and specifications in this family.

Visit our Allen-Bradley Industrial Automation Products master category for the complete range of controllers, drives, motors, HMIs, and accessories.

NEW product in original sealed packaging. The product may be of older version or design. The packaging may have markings, signs of discoloration, and wear. DDPARTSSOLUTION Warranty: 1 Year. Manufacturer's Warranty and Support NEVER apply
