Allen-Bradley 140G-G6C3-C30

Allen-Bradley 140G-G6C3-C30

Overview

The Allen-Bradley 140G-G6C3-C30 is a 3-pole molded case circuit breaker (MCCB) from the 140G G-frame series, rated for 600 amps with a thermal-magnetic trip unit. Designed to protect electrical circuits from overloads and short circuits, this MCCB offers reliable performance for demanding commercial and industrial applications. It complies with UL 489 and IEC 60947-2 standards and supports flexible installation in power distribution panels.

Key Features

• Frame Size: G-frame

• Rated Current: 600 A

• Number of Poles: 3

• Trip Unit Type: Thermal-magnetic (fixed)

• Interrupting Capacity: 35 kA @ 480V AC

• Voltage Rating: Up to 600V AC

• Mounting Type: Fixed

• Standards Compliance: UL 489, IEC 60947-2

Technical Specifications

• Catalog Number: 140G-G6C3-C30

• Frequency: 50/60 Hz

• Operating Temperature: -25°C to +70°C

• Terminal Type: Line and load lugs (varies by configuration)

• Breaking Capacity:

  • 35 kA @ 480V AC

  • 18 kA @ 600V AC

• Certifications: CE, UL, CSA

• Dimensions: Approx. 275 x 105 x 120 mm (HxWxD, varies by version)

Applications

• Power distribution panels

• Motor control centers (MCCs)

• Industrial machinery

• HVAC systems

• Data centers and commercial buildings

Why Choose the 140G-G6C3-C30

• High breaking capacity up to 35kA at 480V AC

• Robust 600A protection for heavy-duty loads

• UL and IEC compliance for global applications

• Compact G-frame footprint for space-saving installations

• Trusted Allen-Bradley quality and durability

Order Now

The Allen-Bradley 140G-G6C3-C30 molded case circuit breaker is available and ready to ship worldwide.
