Allen-Bradley Kinetix 5700 – High-Power Servo Drives for Complex Motion Control

The Allen-Bradley Kinetix 5700 is a scalable, high-performance servo drive solution built for complex, high-power applications. Part of Rockwell Automation’s Integrated Architecture®, the Kinetix 5700 simplifies the deployment of multi-axis motion systems with less wiring, easier integration, and advanced safety features.

At DDPARTSSOLUTION, we offer new and surplus Kinetix 5700 Servo Drives, modules, accessories, and verified inventory—ready for fast global shipping. Whether you're designing new motion systems or upgrading existing machines, we provide the powerful Allen-Bradley solutions your automation needs.

What is the Kinetix 5700 Servo Drive?

The Kinetix 5700 (catalog series 2198) is a modular EtherNet/IP servo drive platform engineered to support large-scale, high-speed applications. It provides coordinated multi-axis motion control with real-time performance and full compatibility with Logix 5000 controllers via Studio 5000 Logix Designer®.

Common Use Cases:

• Automotive and aerospace manufacturing

• High-speed packaging systems

• Material handling automation

• Robotics and multi-axis CNC systems

• Converting and printing equipment

Key Features of Kinetix 5700

• Dual-axis and single-axis modules

• Power range from 1.6 to 112 kW

• EtherNet/IP and CIP Motion support

• Integrated Safe Torque Off (STO) and GuardLogix® ready

• Kinetix TLP motor compatibility

• Energy-efficient regenerative bus sharing

• Reduced cabinet space with slim design

• Quick commissioning with Studio 5000

Kinetix 5700 Servo Drives User Manual Overview

The Kinetix 5700 User Manual provides comprehensive installation, configuration, and troubleshooting guidance. It includes:

• Drive wiring and power setup

• Safe Torque Off wiring procedures

• Motor and encoder feedback connections

• Parameter tuning and drive diagnostics

• Drive configuration with Studio 5000

• Safety integration and performance monitoring

Need help understanding the manual? Contact DDPARTSSOLUTION for technical guidance or support locating documentation.

Allen-Bradley Kinetix 5700 Product Profile

• Series: 2198

• Input Voltage: 460V AC, 3-phase

• Compatible Motors: VPL, VPH, and third-party motors

• Axes: Single and dual-axis options

• Certifications: CE, UL, RoHS

• Cooling Methods: Natural convection and forced-air cooling

• Mounting: DIN rail or panel-mounted

• Applications: High-inertia, high-speed, multi-axis motion systems

How to Install a Kinetix 5700 Servo Drive

1. Mount the Drive Securely: Install the drive in a clean, dry panel with proper spacing for ventilation. Use DIN rail or direct panel mount as recommended.

2. Connect Input Power: Wire the three-phase AC power supply to the input terminals according to the user manual.

3. Wire Motor and Feedback Cables: Connect TLP or compatible servo motors and encoders using Rockwell-approved cables.

4. Setup Safe Torque Off (STO): Wire STO inputs if using integrated safety. Confirm compliance with safety requirements.

5. Network Integration: Connect EtherNet/IP communication cables. Assign IP addresses through BootP/DHCP or Studio 5000.

6. Commissioning and Tuning: Use Studio 5000 Logix Designer® for initial setup, drive tuning, axis configuration, and diagnostics.

Need support with your installation? Our technical team at DDPARTSSOLUTION is ready to help.

Frequently Asked Questions About Kinetix 5700

What controllers are compatible with the Kinetix 5700?
It works with CompactLogix and ControlLogix controllers via EtherNet/IP and CIP Motion.

What power range does it support?
It supports from 1.6 kW up to 112 kW—ideal for small to very large applications.

Is safety integrated?
Yes. The Kinetix 5700 includes Safe Torque Off (STO) and supports GuardLogix® safety integration.

Can it be used with induction motors?
Yes. In addition to servo motors, Kinetix 5700 can also run induction motors, expanding application flexibility.

Do you have stock available?
Yes. DDPARTSSOLUTION carries a verified stock of Kinetix 5700 drives and components, ready to ship.

Do you ship internationally?
Absolutely. We offer fast and reliable worldwide shipping.

Why Buy from DDPARTSSOLUTION?

At DDPARTSSOLUTION, we specialize in supplying high-performance automation solutions from top brands like Allen-Bradley. Our customers benefit from:

• ✔ Verified inventory of servo drives and parts

• ✔ New and surplus options available

• ✔ Competitive pricing and fast turnaround

• ✔ Worldwide shipping from our U.S. warehouse

• ✔ Expert support for installations, part matching, and upgrades

Request a Quote Today

Looking for Kinetix 5700 servo drives or installation assistance? Contact our sales team for current pricing and availability.

📞 Phone: +1 (689) 275-3558
📧 Email: sales@ddpartssolution.com
🌐 Website: www.ddpartssolution.com

DDPARTSSOLUTION – Your global source for Allen-Bradley Kinetix motion solutions and industrial automation parts.
