Siemens 3RV2011-0HA10 | SIRIUS Motor Starter Protector

Overview:

The Siemens 3RV2011-0HA10 is a compact motor starter protector from the SIRIUS series, specifically designed to safeguard motors against overloads and short circuits. With a size S00 frame, it offers a thermal overload release adjustable between 0.55 to 0.8 A and a fixed magnetic release at 10 A. This device ensures reliable motor protection in various industrial applications.

Key Features:

• Adjustable Thermal Overload Release: 0.55 to 0.8 A, allowing precise protection settings based on motor requirements.
• Fixed Magnetic Release: Set at 10 A for immediate response to short-circuit conditions.
• Compact Size S00 Frame: Facilitates space-saving installation in control panels.
• Screw Terminals: Ensure secure and straightforward wiring connections.
• Standard Switching Capacity: Suitable for motors up to 0.18 kW at 400 V.

Technical Specifications:

• Product Type: Motor Starter Protector
• Part Number: 3RV2011-0HA10
• Frame Size: S00
• Thermal Overload Release Range: 0.55 to 0.8 A
• Magnetic Release Setting: 10 A
• Operational Voltage: Up to 690 V
• Operational Current at AC-3 (400 V): 0.8 A
• Power Rating at AC-3 (400 V): 0.18 kW
• Mounting Method: Screw and snap-on mounting onto 35 mm DIN rail according to DIN EN 60715
• Dimensions (H x W x D): 97 mm x 45 mm x 97 mm
• Weight: Approximately 0.277 kg
• Protection Class: IP20
• Operating Temperature Range: -20°C to +60°C
• Standards Compliance: IEC 60947-4-1, IEC 60947-2

Applications:

• Industrial Automation: Protects motors in automated machinery from overload and short-circuit conditions.
• Conveyor Systems: Ensures reliable operation by safeguarding motors driving conveyor belts.
• Pumping Stations: Provides essential protection for motors in various pumping applications.
• HVAC Systems: Secures motors in heating, ventilation, and air conditioning equipment against electrical faults.

The Siemens 3RV2011-0HA10 motor starter protector offers dependable and efficient motor protection, making it a vital component in diverse industrial settings.
