Schneider Electric ATV310HU75N4E | 7.5 kW Variable Speed Drive

Schneider Electric ATV310HU75N4E | 7.5 kW Variable Speed Drive – 380–460V AC, 3-Phase, Altivar 310 Series

Overview

The Schneider Electric ATV310HU75N4E is a 7.5 kW (10 hp) variable speed drive from the Altivar 310 series, designed to provide efficient and reliable motor control for three-phase asynchronous motors. Operating within a voltage range of 380 to 460V AC, this drive is suitable for various industrial applications requiring precise speed and torque management.

Key Features

• Power Rating: 7.5 kW (10 hp)

• Input Voltage: 380–460V AC, 3-phase

• Output Frequency: 0.5 to 400 Hz

• Control Type: Sensorless vector control for asynchronous motors

• Overload Capacity:

  • Heavy Duty: 150% of nominal motor current for 60 seconds

  • Normal Duty: 110% of nominal motor current for 60 seconds

• Integrated Functions:

  • PID regulator

  • Multi-speed settings

  • Acceleration and deceleration ramps

• User Interface:

  • Integrated display with navigation buttons

  • Optional remote keypad

• Communication: Modbus RTU via RJ45 port

• Protection Features:

  • Overcurrent

  • Overvoltage

  • Undervoltage

  • Overheating

  • Short-circuit

• Certifications: CE, UL, CSA, C-Tick

Technical Specifications

• Model Number: ATV310HU75N4E

• Series: Altivar 310

• Motor Control: Sensorless vector control

• Input Voltage Range: 380–460V AC (-15% to +10%)

• Input Frequency: 50/60 Hz ±5%

• Output Voltage: 0 to input voltage

• Output Frequency Range: 0.5 to 400 Hz

• Rated Output Current:

  • Heavy Duty: 17 A

  • Normal Duty: 22.8 A

• Overload Capacity:

  • Heavy Duty: 150% for 60 seconds

  • Normal Duty: 110% for 60 seconds

• Control Inputs:

  • 6 programmable logic inputs

  • 1 analog input (0–10V or 4–20 mA)

• Control Outputs:

  • 1 relay output

  • 1 analog output (0–10V)

• Degree of Protection: IP20

• Cooling Method: Forced convection

• Operating Temperature: -10°C to +55°C

• Storage Temperature: -25°C to +70°C

• Dimensions (H x W x D): 232 mm x 150 mm x 172 mm

• Weight: Approximately 4.5 kg

Applications

• Pumps and Fans: Efficient control of flow and pressure

• Conveyors: Smooth speed regulation for material handling

• Mixers and Agitators: Consistent torque delivery for uniform mixing

• HVAC Systems: Energy-efficient climate control

• General Machinery: Versatile motor control for various industrial equipment

Why Choose the ATV310HU75N4E?

• Energy Efficiency: Optimizes motor performance to reduce energy consumption

• Robust Design: Built to withstand demanding industrial environments

• Flexible Integration: Compatible with various control systems and communication protocols

• User-Friendly Interface: Simplifies setup and operation

• Comprehensive Protection: Ensures safety and longevity of both the drive and connected motors

Order Now

Available for immediate worldwide shipping. Contact us for accessories, spare parts, and technical support to ensure seamless integration into your system.

NEW product in original sealed packaging. The product may be of older version or design. The packaging may have markings, signs of discoloration, and wear. DDPARTSSOLUTION Warranty: 1 Year. Manufacturer's Warranty and Support NEVER apply
